Catalyst C9300-48P-E - Managed - L2/L3 - Gigabit Ethernet (10/100/1000) - Vollduplex - Power over Ethernet (PoE) - Rack-Einbau

Mfg. SKU: C9300-48P-E

Artikelnummer: 1051579

EAN: 0889728035736

General
Switch type
Managed
Switch layer
L2/L3
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity
48
Full duplex
Y
MAC address table
32000 entries
Switching capacity
256 Gbit/s
Networking standards
IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3ap,IEEE 802.3bz,IEEE 802.3u,IEEE 802.3z
Power over Ethernet (PoE)
Y
Rack mounting
Y
CHF 4,458.73 CHF 4,139.95

Wählen Sie das vorgeschriebene Produkt

Tooltip
Die Auswahl eines Produkts aus der folgenden Liste ist vom Hersteller für den ordnungsgemäßen Betrieb des aktuell angesehenen Produkts vorgeschrieben.
Verfügbarkeit: Auf Anfrage

Cisco Catalyst C9300-48P-E network switch Managed L2/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey

Catalyst® 9300 Series

The Cisco® Catalyst® 9300 Series switches are Cisco’s lead stackable enterprise switching platform built for security, IoT, mobility, and cloud. They are the next generation of the industry’s most widely deployed switching platform. Catalyst 9300 Series switches form the foundational building block for Software-Defined Access (SD-Access), Cisco’s lead enterprise architecture. At up to 1TB, they are the industry’s highest-density stacking bandwidth solution with the most flexible uplink architecture. The Catalyst 9300 Series is the first optimized platform for high-density Wi-Fi 6 and 802.11ac Wave2. It sets new maximums for network scale. These switches are also ready for the future, with an x86 CPU architecture and more memory, enabling them to host containers and run third-party applications and scripts natively within the switch.

The Catalyst 9300 Series is designed for Cisco StackWise® technology, providing flexible deployment with support for nonstop forwarding with Stateful Switchover (NSF/SSO), for the most resilient architecture in a stackable (sub-50-ms) solution. The highly resilient and efficient power architecture features Cisco StackPower®, which delivers high-density Power over Ethernet Plus (PoE+), 60W Cisco Universal Power over Ethernet (Cisco UPOE) and 90W Cisco UPOE®+ ports. The switches are based on the Cisco Unified Access™ Data Plane 2.0 (UADP) architecture which not only protects your investment but also allows a larger scale and higher throughput. Catalyst 9300X models are based on a new ASIC, UADP 2.5sec, which adds Crypto support in hardware, including IPSEC. A modern operating system, Cisco IOS® XE with programmability offers advanced security capabilities and Internet of Things (IoT) convergence.

Cisco Catalyst C9300-48P-E network switch Managed L2/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey

The Foundation of Software-Defined access

Advanced persistent security threats. The exponential growth of Internet of Things (IoT) devices. Mobility everywhere. Cloud adoption. All of these require a network fabric that integrates advanced hardware and software innovations to automate, secure, and simplify customer networks. The goal of this network fabric is to enable customer revenue growth by accelerating the rollout of business services.

The Cisco Digital Network Architecture (Cisco DNA) with Software-Defined Access (SD-Access) is the network fabric that powers business. It is an open and extensible, software-driven architecture that accelerates and simplifies your enterprise network operations. The programmable architecture frees your IT staff from time-consuming, repetitive network configuration tasks so they can focus instead on innovation that positively transforms your business. SD-Access enables policy-based automation from edge to cloud with foundational capabilities. These include:

  1. Simplified device deployment
  2. Unified management of wired and wireless networks
  3. Network virtualization and segmentation
  4. Group-based policies
  5. Context-based analytics.

Cisco DNA software

Cisco DNA Software offers a valuable and flexible way to buy software for the access, WAN, and data center domains. At each stage in the product lifecycle, Cisco DNA Software helps make buying, managing, and upgrading your network and infrastructure software easier. Cisco DNA Software provides:

  1. Flexible licensing models to smoothly distribute customers’ software spending over time
  2. Investment protection for software purchases through software services–enabled license portability
  3. Access to updates, upgrades, and new technology from Cisco through Cisco®Software Support Services (SWSS)
  4. Lower cost of entry with the new Cisco DNA Subscription for Switching model
  5. Access to end-to-end service assurance through Cisco ThousandEyes* Network and Application Synthetics (included with Cisco DNA Advantage and Premier licenses).
Cisco Catalyst C9300-48P-E network switch Managed L2/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey
Cisco Catalyst C9300-48P-E network switch Managed L2/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey

Additional Product Notes

  1. Highest wireless scale for Wi-Fi 6 and 802.11ac Wave 2 access points supported on a single switch with select models
  2. C9300 and C9300L models are based on the Cisco UADP 2.0 Application-Specific Integrated Circuit (ASIC) with programmable pipeline and microengine capabilities, along with template-based, configurable allocation of Layer 2 and Layer 3 forwarding, Access Control Lists (ACLs), and Quality of Service (QoS) entries
  3. C9300X models are based on UADP 2.5sec ASIC which adds line rate support for Crypto, including 100G IPSec
  4. x86 CPU complex with 8-GB memory, and 16 GB of flash and external USB 3.0 SSD pluggable storage slot (delivering up to 240GB of storage with an option SSD drive) to host containers. C9300X models support 16GB of memory
  5. USB 2.0 slot to load system images and set configurations
  6. Up to 1 TBps of local stackable switching bandwidth
  7. Deeper buffer and higher scale model options for rich multi-media content delivery applications
  8. Flexible and dense uplink offerings with 1G, Multigigabit, 10G, 25G, 40G and 100G in the form of fixed or modular uplinks
  9. Easy transition from 10G to 25G with dual-rate optics
  10. Flexible downlink options with 1G Copper and Fiber as well as the densest Multigigabit links
  11. With a mix of Copper (1G up to 10G) and Fiber (1G up to 25G) supported in a single stack, multiple flexible deployment scenarios are enabled, including 2-Tier, 3-Tier and Hybrid architectures
  12. Leading PoE capabilities with up to 384 ports of PoE per stack, PoE+, and high density IEEE 802.3bt - 60W UPOE, and 90W Cisco UPOE®+
  13. Intelligent Power Management with Cisco StackPower technology, providing power stacking among members for power redundancy. Stackpower pools the power supplies across the stack to be used redundancy and supplemental power purposes
  14. Line-rate, hardware-based Flexible NetFlow (FNF), delivering flow collection of up to 128,000 flows with select models
  15. IPv6 support in hardware, providing wire-rate forwarding for IPv6 networks
  16. Dual-stack support for IPv4/IPv6 and dynamic hardware forwarding table allocations, for ease of IPv4-to-IPv6 migration
  17. Support for both static and dynamic NAT and Port Address Translation (PAT)
  18. IEEE 802.1ba AV Bridging (AVB) built in to provide a better audio and video experience through improved time synchronization and QoS
  19. Precision Time Protocol (PTP; IEEE 1588v2) provides accurate clock synchronization with sub-microsecond accuracy making it suitable for distribution and synchronization of time and frequency over network
  20. Cisco IOS XE, a modern operating system for the enterprise with support for model-driven programmability including NETCONF, RESTCONF, YANG, on-box Python scripting, streaming telemetry, container-based application hosting, and patching for critical bug fixes. The OS also has built-in defenses to protect against runtime attacks
  21. End-to-end visualization of the path from campus/branch to clouds/DC with Cisco ThousandEyes Network and Application Synthetics (included with Cisco DNA Advantage and Premier licenses)
  22. SD-Access: Cisco Catalyst 9300 Series switches form the foundational building block for SD-Access, Cisco’s lead enterprise architecture:
    1. Policy-based automation from edge to cloud
    2. Simplified segmentation and micro-segmentation, with predictable performance and scalability
    3. Automation through Cisco DNA Center
    4. Policy handled through the Cisco Identity Services Engine (ISE)
    5. Network assurance provided through the Cisco DNA Center
    6. Faster launch of new business services and significantly improved issue resolution time
  23. Plug and Play (PnP) enabled: A simple, secure, unified, and integrated offering to ease new branch or campus device rollouts or updates to an existing network
  24. Advanced security
    1. Encrypted Traffic Analytics (ETA): You benefit from the power of machine learning to identify and take actions toward threats or anomalies in your network, including malware detection in encrypted traffic (without decryption) and distributed anomaly detection
    2. Support for AES-256 with the powerful MACsec 256-bit encryption algorithm available on all models
    3. Trustworthy solutions: Hardware anchored Secure Boot and Secure Unique Device Identification (SUDI) support for Plug and Play, to verify the identity of the hardware and software
Cisco Catalyst C9300-48P-E network switch Managed L2/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey
Cisco Catalyst C9300-48P-E network switch Managed L2/L3 Gigabit Ethernet (10/100/1000) Power over Ethernet (PoE) Grey
Basic switching RJ-45 Ethernet ports type Switch type Net Ports Quantity Switching capacity DHCP features
Gigabit Ethernet (10/100/1000) Managed 48 256 Gbit/s DHCP snooping
Design
Rack mounting
Y
Product colour
Grey
Management features
Switch type
Managed
Switch layer
L2/L3
Quality of Service (QoS) support
Y
MIB support
Y
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity
48
Basic switching RJ-45 Ethernet ports type
Gigabit Ethernet (10/100/1000)
Power over Ethernet (PoE)
Power over Ethernet (PoE)
Y
Power over Ethernet plus (PoE+) ports quantity
48
Data transmission
MAC address table
32000 entries
Switching capacity
256 Gbit/s
Forwarding rate
190.48 Mpps
Jumbo frames support
Y
Jumbo frames
9198
Network
Networking standards
IEEE 802.1D,IEEE 802.1Q,IEEE 802.1p,IEEE 802.1s,IEEE 802.1w,IEEE 802.1x,IEEE 802.3ad,IEEE 802.3af,IEEE 802.3ap,IEEE 802.3bz,IEEE 802.3u,IEEE 802.3z
Full duplex
Y
VLAN support
Y
Number of VLANs
4094
Multicast features
Multicast support
Y
Security
DHCP features
DHCP snooping
Access Control List (ACL)
Y
Operational conditions
Operating temperature (T-T)
-5 - 40 °C
Storage temperature (T-T)
-40 - 70 °C
Operating relative humidity (H-H)
5 - 90 %
Operating altitude
0 - 3000 m
Weight & dimensions
Width
445 mm
Depth
445 mm
Height
44 mm
